Deep Groove Ball Bearing 6030 C3
₹13,970.00
+ ₹2,514.60 (18% GST)
| Price Excluding Taxes | ₹13,970.00 |
| + (18% GST applicable) | ₹2,514.60 |
| Price Including Taxes | ₹16,484.60 |
In Stock
SKU
103176
Available Stock Quantity:
1
Is Returnable:
No
Ageing:
<5 Years
Unit of Measurement:
Nos
Deep Groove Ball Bearing 6030 C3
Type: Single-row deep groove ball bearing
Model: 6030 C3
Clearance: C3 greater than normal radial clearance for thermal expansion and high-speed operation
Design: Open type (no seals or shields)
Material Code: 103176
? Technical Specifications
Parameter Value
Bore Diameter (d)150 mm
Outer Diameter (D)225 mm
Width (B)35 mm
Dynamic Load Rating (C) ~125 kN
Static Load Rating (C?) ~125 kN
Reference Speed ~6000 RPM
Limiting Speed ~3800 RPM
Cage Material Sheet steel
Bearing Material Bearing-grade steel (e.g., SAE 52100)
Weight ~4.2 kg
Internal Clearance C3
Operating Temp Range 30°C to +150°C
Manufacturer Details
SKF Model: 6030/C3 (Explorer series available)
FAG / NSK / NTN / ZKL / NBC Equivalent models available across global and Indian markets
Material Composition:
Rings & Balls: High-carbon chromium steel
Cage: Stamped steel
Heat stabilization: Suitable up to 150°C
HSN Code & GST
Item Detail
HSN Code 84821013
GST Rate 18%
Classification Radial-type ball bearings with bore diameter > 50 mm
Ageing & Service Life
Heat Treatment: Bearings are stabilized for dimensional integrity up to 150°C
Lubrication: Open type requires external lubrication; service life depends on grease/oil quality
Expected Life: >20,000 hours under rated conditions with proper lubrication and alignment
Ageing Factors: Primarily influ
Model: 6030 C3
Clearance: C3 greater than normal radial clearance for thermal expansion and high-speed operation
Design: Open type (no seals or shields)
Material Code: 103176
? Technical Specifications
Parameter Value
Bore Diameter (d)150 mm
Outer Diameter (D)225 mm
Width (B)35 mm
Dynamic Load Rating (C) ~125 kN
Static Load Rating (C?) ~125 kN
Reference Speed ~6000 RPM
Limiting Speed ~3800 RPM
Cage Material Sheet steel
Bearing Material Bearing-grade steel (e.g., SAE 52100)
Weight ~4.2 kg
Internal Clearance C3
Operating Temp Range 30°C to +150°C
Manufacturer Details
SKF Model: 6030/C3 (Explorer series available)
FAG / NSK / NTN / ZKL / NBC Equivalent models available across global and Indian markets
Material Composition:
Rings & Balls: High-carbon chromium steel
Cage: Stamped steel
Heat stabilization: Suitable up to 150°C
HSN Code & GST
Item Detail
HSN Code 84821013
GST Rate 18%
Classification Radial-type ball bearings with bore diameter > 50 mm
Ageing & Service Life
Heat Treatment: Bearings are stabilized for dimensional integrity up to 150°C
Lubrication: Open type requires external lubrication; service life depends on grease/oil quality
Expected Life: >20,000 hours under rated conditions with proper lubrication and alignment
Ageing Factors: Primarily influ
| HSN Code | 85362030 |
|---|---|
| Shipping Option | Self pick up |
| Available for | Everyone |
| Organization Name | OPG Power Generation Private Limited |
| Packed | Yes |
| Rusted | No |
